24114068 / XE-70M / Q1MCMCIR_E34 / E334874 / R15-3 INGERSOLL RAND MODEL AIRMASTER Q1 24114068 / XE-70M / Q1MCMCIR_E34 / E334874 / R15-3 BUS RS485 OPTIMIZED FOR ROTARY SCREW COMPRESSOR CONTROLLERS
Free
INGERSOLL RAND MODEL AIRMASTER Q1 24114068 / XE-70M Q1MCMCIR_E34 / E334874 / R15-3 BUS RS485 OPTIMIZED FOR ROTARY SCREW COMPRESSOR CONTROLLERS
Main Part Number: 24114068
Manufacturer Part Number: 24114068
INGERSOLL RAND Model: 24114068 XE-70M AirMaster Q1 is a "mid-range" member of the AirMaster family ideally suited to positive displacement rotary screw, vane and piston compressor or vacuum applications.
Using the powerful CMC ARM CORTEX-M3 processor from NXP, INGERSOLL RAND Model: 24114068 XE-70M Q1 algorithms are designed to ensure efficient operational configurations enhanced by PLC options when required.
The Ingersoll Rand 24114068 XE-70M is designed for rotary screw compressors, the new Xe-70M controller provides you with a full asset control and superior connectivity. It allows for easy diagnostics that lead to less down time for your compressed air system and helps you increase productivity due to automated data logging and report generation. ; Clear, intuitive navigation ensures ease of use and automated email notifications provide you with a peace of mind that your system is running as it should!
WHAT IT OFFERS
-
Automatic email notification of alarms and trips
-
Automatic performance log, inspection log, and
graph DESIGN
-
2.6" 240 x 160 monochrome graphic display
-
Large navigation buttons, intuitive navigation
control, and high intensity LED indicators CONNECTIVITY
-
Sequence up to 4 compressors without additional
hardware / software
-
Integrates seamlessly with Xi system controls (no
interface required)
-
Standard Modbus RTU protocol
EXTRA FEATURES
• Start/Stop Control
• Manual Load/Unload Control
• Automatic Load Control (Auto-Restart) • Integrated Dryer Control
• Modulation (Fixed Speed Only)
• Mod/ACS (Fixed Speed Only)
• Lead/Lag (Fixed Speed Only) -
274
• Blower Control (Includes Low Ambient Option) • Power Out Restart Option
• Progressive Adaptive Control (PAC)
Optional Features• Optional Eco Mode gives you access to data packed web pages, accessed via standard web browsers, to view asset performance and inspection logs and graphs
-
