P1794915-0104 Cooper Turbocompressor Quad 2000 Board Model P1794915-0104 Quad 2000 Turbocompressor Microprocessor Controller
479
Free
- Cooper Board Model P1794915-0104 Turbocompressor Quad 2000 Microprocessor ControllerOver 30 years of providing answers to Centrifugal Compressor control and protection issues the Cooper Board Model P1794915-0104 Turbocompressor Quad 2000 Microprocessor Control system provides an advanced intelligent operating algorithm.Learning from adjust and response technology the Cooper Board Model P1794915-0104 Turbocompressor Quad 2000 Microprocessor Controller communicates operating information via a user interface which allows the user to fine tune the controller modes to the main drive, oil pump lubricator, motor starter, panel heaters or coolers, valves etc to minimize energy loss and maximize efficiency.There are 3 Control Modes.Auto-Dual: Basic LOAD-UNLOAD-RELOAD function.Constant Pressure: Recommended and maintains system pressure at a fixed level which minimizes energy usage and atmospheric blow-off.Contant Mass Flow: Running constantly in the LOAD mode control is provided by Air Mass Measurement rather than Process Air Pressure.Cooper Board Model P1794915-0104 Turbocompressor Quad 2000 Microprocessor Controller Control Panel Interface.
- Display
- Numeric Keypad
- Silence Key with Alarm and Trip Indicator Lights
- Control Reset Key and Ready to Start Indicator Light
- Start Key
- Stop Key
- Operational Method Keypad
- Power OFF/ON Switch
- Emergency Stop Button
