  • 39825716 Ingersoll Rand NLTS100-200 SIERRA Rotary Air Compressor Controller

    The39825716 Ingersoll Rand NLTS 100-200 Rotary Air Compressor Controller is drivenby an enhanced version of Ingersoll Rands exclusive intellisys SIERRAcontroller.

    Theoperation of the 39825716 Ingersoll Rand NLTS 100-200 SIERRA Rotary AirCompressor Controller is simple with all adjustments and display informationaccessed through a touch sensitive membrane panel.

    The39825716 Ingersoll Rand NLTS 100-200 SIERRA Rotary Air Compressor Controllermonitors all compressor functions and displays information in plain language,not codes.

    The39825716 Ingersoll Rand NLTS 100-200 SIERRA Rotary Air Compressor Controllermonitors 23 essential compressor operating parameters 20 times per second. Inthe event any parameter deviates from its pre-programmed limit, the controllerautomatically displays a warning and/or stops the compressor. The display thenindicates the problem and the sequence of events leading to the shutdown. Thisexclusive feature saves costly troubleshooting expenses and keeps downtime toan absolute minimum.

    StandardDisplay Readouts

    • Package discharge pressure and temperature
    • First stage discharge pressure and temperature
    • Second stage inlet temperature
    • Second stage pressure and temperature
    • Bearing oil pressure and temperature
    • Total hours/Loaded hours
    • Inlet filter condition
    • Oil filter pressure drop

    AdjustableOperating Parameters

    • On-line pressure

    • Off-line pressure

    • Display time

    • Load delay time

    • Star-Delta transition time

    • Auto start/stop shutdown time

    • Condensate drain interval time

    • Maximum first stage temperature

    • Maximum second stage temperature

    AirCapacity Control System

    TheSIERRA's compressed air output is also controlled through the Intellysissystem.

    Dischargepressure points (load and unload) are entered into the intellysis by using thetouch sensitive keypad. The intellysis then monitors the discharge pressure 20times a second, assuring delivery of the desired pressure.

    Options

    Automaticstart-stop control, remote start-stop, automatic Power Outage Restart andmultiple unit sequencing capability are all available options.
