SIEMENS QUINCY 6AV7820-0AA00-1AC0 SIEMENS QUINCY SIMATIC PANEL PC 577 COMPRESSOR CONTROLLER

MEI International

  • SIEMENS QUINCY 6AV7820-0AA00-1AC0 PC 577 SIEMENS SIMATIC DISPLAY PANEL PC 577 COMPRESSOR CONTROLLER.

    NOTE: FOR THE LATEST FUNCTION AND PERFORMANCE UPDATES CHECK WITH THE EQUIPMENT MANUFACTURER.

    Description:

    The device serves as a base for PC-based HMI devices, the Panel PCs. The Panel PC 577 fulfills the basic requirements for industrial compatibility and provides high performance at a low price.

    The device consists of the control unit with a key or touch panel and the computer unit. The control unit is screwed to the back of the computer unit.

    General features

    Processor - Intel® Pentium 4 2.4 GHz - Intel® Celeron 2.0 GHz
    Chipset Intel 865G
    Main memory 256 MB = 2 x 128 MB SDRAM or 1 x 256 MB SDRAM
    512 MB = 2 x 256 MB SDRAM
    4 slots, expandable to 4 GB maximum
    Slots for add-ons

    • Uppermost slot is suitable for WinAC Slot module.

    • 2 x PCI 175 mm long (below)

    Device variants

    The device is available with different control units which are distinguished by the size of the display and by a membrane keyboard or touch screen.

     Keyboard variants

    • 12"/15" TFT technology
    • Color display with backlighting
    • Membrane keyboard with alphanumeric keys, numeric keys, cursor keys and        control keys
    • Function keys and softkeys
    • Integrated mouse
    • Softkeys, <Shift> und <ACK>
    • Front-mounted USB 2.0 interface for
    connecting external I/O modules

    Touch screen variants

    • 12''/15''/19'' TFT technology
    • Color display with backlighting
    • Front-mounted USB 2.0 interface for connecting external I/O modules
    Graphics On-board graphics (865G chipset)
    12'': 800 x 600, 60 Hz
    15'': 1024 x 768, 60 Hz
    19'': 1280 x 1024, 60 Hz



    SIEMENS QUINCY 6AV7820-0AA00-1AC0 PC 577 SIEMENS SIMATIC DISPLAY PANEL.


    Power supply

    110/230 V AC, 350 W; variable voltage with shortterm buffering against power failure at maximum 16 ms
    Drives optional CD-ROM drive
    Hard disks ≥ 40 GB HDD small, 1x 2.5"



    Operating system

    Optional Preinstalled, also installed on the Restore CD
    - Windows 2000 Professional MUI*
    - Windows XP Professional MUI*
    *MUI: Multi-language user interface; German, English, French, Italian, Spanish, Japanese, Korean, Chinese simplified and Chinese traditional.

    Description

    Interfaces
    Installed via expansion cards: PROFIBUS / MPI CP 5611-compatible
    (not included in the scope of supply)
    Ethernet LAN 10/100/1000 Mbps
    USB 4x USB 2.0 high current, external
    2x USB 2.0 high current available, internal via male connector
    1x USB 2.0 high current, front mounted
    Serial interfaces COM1 V.24
    Parallel interfaces LPT1
    Keyboard PS/2
    Mouse PS/2

    SIEMENS QUINCY 6AV7820-0AA00-1AC0 PC 577 SIEMENS SIMATIC DISPLAY PANEL

     Accessories not supplied with the device package.

    SIMATIC PC

    Siemens 6AV7820-0AA00-1AC0 simatic panel pc 577 12" touch; 800x600; standard ac110-230v, power cable europe celeron p4 2,0 ghz; 256mb ddr400 sdram (2x128mb); 40 gbyte harddisk 2,5"; dvd-rom; windows xp prof. sp2
